BMW 1 series E81/E82/E87/E88 facelift (2007-2011) clamping bracket erected hall sensor Wiring diagram

This page shows the only wiring diagram for the component.clamping bracket erected hall sensor, which is found in the car BMW 1 series E81/E82/E87/E88 facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram clamping bracket erected hall sensor (1 of 1)

Wiring diagram clamping bracket erected hall sensor for BMW 1 series E81/E82/E87/E88 facelift (2007-2011)

Get access

BLK/GRN WIRE BLK/RED WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/VIO WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) CLAMPING BRACKET ERECTED HALL SENSOR CLAMPING BRACKET TAKEN DOWN HALL SENSOR CONVERTIBLE TOP COMPARTMENT FLOOR SWITCH CONVERTIBLE TOP COMPARTMENT LID LOCKED HALL SENSOR COWL PANEL LOCKED HALL SENSOR GRN/BLK WIRE GRY/BLK WIRE GRY/GRN WIRE LOCKING COWL PANEL DRIVE MAIN PILLAR ERECTED HALL SENSOR MAIN PILLAR TAKEN DOWN HALL SENSOR NCA WIRE RED WIRE TENSIONING BAR EXTENDED HALL SENSOR TOWING HITCH RELEASE WHT/BRN WIRE WHT/YEL WIRE WIND SCREEN COWL PANEL LATCH INCREMENTAL TRANSDUCER DRIVE UNIT YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE YEL/VIO WIRE

Go to component: -> Convertible top circuit (2 of 2) -> CLAMPING BRACKET ERECTED HALL SENSOR
