Hifi radio circuit, with ccc & m-ask for BMW 1 series E81/E82/E87/E88 facelift 2 (2011-2014)

AUX-IN CONNECTION BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE BRN/ORG WIRE CCC/M-ASK CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM DYNAMIC STABILITY CONTROL (DSC) (LEFT REAR OF ENGINE COMPT) ELECTRONICS JUNCTION BOX FUSE FUSE 18 FUSE 19 GRN WIRE GRY WIRE GRY/RED WIRE HOT W/ HOT W/ BISTABLE RELAY ENERGIZED JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT MICROPHONE NCA WIRE ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RELAY ENERGIZED TCU VIDEO MODULE (LEFT SIDE OF REAR COMPT) W/ CONVERTIBLE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE

BLK WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE CCC/M-ASK CD CHANGER (LEFT SIDE OF REAR COMPT) COUPE DIGITAL TUNER (DAB) (LEFT SIDE OF REAR COMPT) FAN M-ASK/CCC GPS AERIAL GRN WIRE MOST-BUS CONNECTOR NCA WIRE RED/BLK WIRE RED/BLU WIRE ROOF AERIAL RTTI SPLITTER SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) SDARS AERIAL TCU (IF EQUIPPED) W/ CONVERTIBLE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

AERIAL DIVERSITY (BOTTOM CENTER OF REAR WINDOW) AMPLIFIER (LEFT SIDE OF REAR COMPT) BLK WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM CONTROLLER COUPE CONVERTIBLE DASH) FM AERIAL 2 AERIAL (CONVERTIBLE) (CONVERTIBLE) FM AERIAL 3 (CONVERTIBLE) FUSE 15 FUSE 27 GRN WIRE GRY WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT SIDE TRIM PANEL MID-RANGE SPEAKER LEFT SUBWOOFER NCA WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM REAR WINDOW AERIAL (COUPE) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER RIGHT SUBWOOFER VIO WIRE W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION WHT WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE
