Base radio circuit, without cic for BMW 1 series E81/E82/E87/E88 facelift 2 (2011-2014)

AERIAL DIVERSITY (BOTTOM CENTER OF REAR WINDOW) AUX-IN CONNECTION BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE CD CHANGER (LEFT SIDE OF REAR COMPT) COMPUTER DATA LINES SYSTEM CONTROLLER FM AERIAL 3 (CONVERTIBLE) FM AERIAL AERIAL 2 (CONVERTIBLE) (CONVERTIBLE) FUSE 14 FUSE 18 FUSE 19 FUSE 27 GRN WIRE GRY/RED WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT MICROPHONE LEFT REAR MID-RANGE SPEAKER LEFT SUBWOOFER MOST-BUS CONNECTOR NCA WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM RADIO REAR WINDOW AERIAL (COUPE) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT SUBWOOFER ROOF AERIAL (COUPE) SDARS AERIAL (CONVERTIBLE) SAT SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) 3 2 4 1 SDARS AERIAL (CONVERTIBLE) ROOF AERIAL TCU TELEPHONE RETROFIT PACKAGES CONNECTOR TELEPHONE TRANSCEIVER (CENTER OF REAR COMPT) VIO WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE
