Cooling fan circuit for BMW 1 series E81/E82/E87/E88 facelift 2 (2011-2014)

3.0L 3.0L TWIN 3.0L TURBO 3.0L TWIN TURBO 3.0L TWIN TURBO 3.0L 41 13 15 55 17 19 SENS GND SIG 7 8 20 1 14 8 CAN LOW CAN HI ACTIVATION ACTIVATION BLK/BLU WIRE BLK/VIO WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE CHARACTERISTIC MAP THERMOSTAT (REAR OF ENGINE) COMPUTER DATA LINES SYSTEM DME CONTROL MODULE (RIGHT REAR OF ELECTRIC COOLANT PUMP (REAR OF ENGINE) ELECTRIC FAN (FRONT OF ENGINE COMPT) ELECTRIC FAN 400 WATT ELECTRIC FAN 600 WATT ELECTRIC FAN CUT OUT RELAY ENGINE COMPT) ENGINE COOLANT TEMPERATURE SENSOR FUSE HOT AT ALL TIMES HOT W/ DME RELAY ENERGIZED HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) ORG/ WIRE RADIATOR SHUTTER DRIVER (3.0L) (ON RADIATOR GRILLE ASSEMBLY) RADIATOR SHUTTER SOLENOID RED WIRE RED/BLU WIRE RED/GRN WIRE SENS SIG VIO WIRE WHT WIRE WHT/RED WIRE YEL/RED WIRE YEL/WHT WIRE
