BMW 1 series E81/E82/E87/E88 facelift 2 (2011-2014) sdars aerial Wiring diagrams
This page contains all the electrical diagrams for the component. sdars aerial, in which he is found in the car BMW 1 series E81/E82/E87/E88 facelift 2 (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
sdars aerial wiring diagram (1 of 6)
AERIAL (CONVERTIBLE)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CD CHANGER (LEFT SIDE OF REAR COMPT)
COUPE CONVERTIBLE
DIGITAL TUNER (LEFT SIDE OF REAR COMPT)
FUSE 18
FUSE 19
GPS AERIAL
GRN WIRE
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT MID-RANGE SPEAKER
LEFT REAR MID-RANGE SPEAKER
LEFT SUB- WOOFER
MOST-BUS CONNECTOR
NCA WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT FRONT MID-RANGE SPEAKER
RIGHT REAR MID-RANGE SPEAKER
RIGHT SUB- WOOFER
ROOF AERIAL
RTTI SPLITTER
SAT
SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT)
SDARS AERIAL
TCU/ULF/ULF- SBX/ULF-SBX-H 1 2
WHT WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Base radio circuit, with cic (2 of 2) -> SDARS AERIAL
sdars aerial wiring diagram (2 of 6)
BLK WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CCC/M-ASK
CD CHANGER (LEFT SIDE OF REAR COMPT)
COUPE
DIGITAL TUNER (DAB) (LEFT SIDE OF REAR COMPT)
FAN M-ASK/CCC
GPS AERIAL
GRN WIRE
MOST-BUS CONNECTOR
NCA WIRE
RED/BLK WIRE
RED/BLU WIRE
ROOF AERIAL
RTTI SPLITTER
SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT)
SDARS AERIAL
TCU (IF EQUIPPED)
W/ CONVERTIBLE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Hifi radio circuit, with ccc & m-ask (2 of 3) -> SDARS AERIAL
sdars aerial wiring diagram (3 of 6)
