BMW 1 series E81/E82/E87/E88 facelift 2 (2011-2014) left boot lid resistor Wiring diagram
This page shows the only wiring diagram for the component.left boot lid resistor, which is found in the car BMW 1 series E81/E82/E87/E88 facelift 2 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left boot lid resistor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COUPE
FUSE
FUSE 101
GRN WIRE
HEATED REAR WINDOW RELAY
HEATING/AIR CONDITIONING SYSTEM (CENTER OF DASH, ABOVE RADIO)
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
JUNCTION BOX ELECTRONICS
LEFT BOOT LID RESISTOR
NCA WIRE
REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT)
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER (GROUND) LOCKOUT CIRCUIT
REAR WINDOW DEFOGGER (POSITIVE) LOCKOUT CIRCUIT
RED WIRE
RIGHT BOOT LID RESISTOR
WHT WIRE
YEL WIRE
Go to component -> Rear defogger circuit -> LEFT BOOT LID RESISTOR
