BMW 1 series E81/E82/E87/E88 facelift 2 (2011-2014) grn Wiring diagrams

This page contains all the electrical diagrams for the component. grn, in which he is found in the car BMW 1 series E81/E82/E87/E88 facelift 2 (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

grn wiring diagram (31 of 75)

BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER'S SEAT ADJUSTMENT SWITCH DRIVER'S SEAT ANGLE ADJUSTMENT DRIVE (UNDER DRIVER SEAT) DRIVER'S SEAT BACKREST HEATING (IN DRIVER SEAT BACK) DRIVER'S SEAT CUSHION HEATING (IN DRIVER SEAT CUSHION) DRIVER'S SEAT HEIGHT ADJUSTMENT DRIVE UNIT (UNDER DRIVER SEAT) DRIVER'S SEAT MODULE (UNDER DRIVER'S SEAT) DRIVER'S SIDE EASY ENTRY SWITCH FUSE 46 GRN WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS NCA WIRE ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLU WIRE RED/BRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED RELAY ENERGIZED FUSE VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE

Go to component -> Driver"s memory seat circuit (1 of 2) -> GRN WIRE

grn wiring diagram (32 of 75)

BLK WIRE BLK/VIO WIRE BRN WIRE BRN/BLK WIRE CCC/M-ASK DRIVER'S SWITCH CLUSTER ELECTRONICS JUNCTION BOX FOOTWELL MODULE (UNDER LEFT SIDE OF DASH) FRONT CIGAR LIGHTER GEAR INDICATOR LIGHTING GRN WIRE GRY WIRE GRY/RED WIRE HAZARD WARNING SWITCH HOT AT ALL TIMES FUSE HOT AT ALL TIMES FUSE 41 HOT AT ALL TIMES FUSE 86 INTERIOR PANEL) JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LIGHT SWITCH UNIT PASSENGER'S DOOR POWER WINDOW SWITCH RADIO REAR LID RELEASE SWITCH (INTERIOR) RED WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE STEERING COLUMN SWITCH CLUSTER TELEPHONE RETROFIT PACKAGES CONNECTOR VIO WIRE W/ CCC/M-ASK W/O CCC/M-ASK YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/WHT WIRE

Go to component -> Instrument illumination circuit -> GRN WIRE

grn wiring diagram (33 of 75)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 (18 TO 21 PINS NOT USED) 22 AERIAL DIGITAL TUNER (CONVERTIBLE) AERIAL DIGITAL TUNER 2 (CONVERTIBLE) AERIAL DIVERSITY (BOTTOM CENTER OF REAR WINDOW) BLK WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE CAR INFORMATION COMPUTER CIC CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM COUPE CONVERTIBLE ELECTRONICS JUNCTION BOX FM AERIAL 2 FM AERIAL 3 FUSE GRN WIRE GRY/RED WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT MICROPHONE NCA WIRE ORG/ WIRE ORG/GRN WIRE REAR WINDOW AUX-IN AERIAL CONNECTION (COUPE) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE USB PORT WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Navigation circuit, base radio (1 of 2) -> GRN WIRE

grn wiring diagram (34 of 75)

AERIAL (CONVERTIBLE) BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE CD CHANGER (LEFT SIDE OF REAR COMPT) COUPE CONVERTIBLE DIGITAL TUNER (LEFT SIDE OF REAR COMPT) FUSE 18 FUSE 19 GPS AERIAL GRN WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER LEFT SUB- WOOFER MOST-BUS CONNECTOR NCA WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT SUB- WOOFER ROOF AERIAL RTTI SPLITTER SAT SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) SDARS AERIAL TCU/ULF/ULF- SBX/ULF-SBX-H 1 2 WHT WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Navigation circuit, base radio (2 of 2) -> GRN WIRE

grn wiring diagram (35 of 75)

AUX-IN CONNECTION BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE BRN/ORG WIRE CCC/M-ASK CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM DYNAMIC STABILITY CONTROL (DSC) (LEFT REAR OF ENGINE COMPT) ELECTRONICS JUNCTION BOX FUSE FUSE 18 FUSE 19 GRN WIRE GRY WIRE GRY/RED WIRE HOT W/ HOT W/ BISTABLE RELAY ENERGIZED JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT MICROPHONE NCA WIRE ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RELAY ENERGIZED TCU VIDEO MODULE (LEFT SIDE OF REAR COMPT) W/ CONVERTIBLE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE

Go to component -> Navigation circuit, hifi radio with ccc & m-ask (1 of 3) -> GRN WIRE

grn wiring diagram (36 of 75)

BLK WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE CCC/M-ASK CD CHANGER (LEFT SIDE OF REAR COMPT) COUPE DIGITAL TUNER (DAB) (LEFT SIDE OF REAR COMPT) FAN M-ASK/CCC GPS AERIAL GRN WIRE MOST-BUS CONNECTOR NCA WIRE RED/BLK WIRE RED/BLU WIRE ROOF AERIAL RTTI SPLITTER SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) SDARS AERIAL TCU (IF EQUIPPED) W/ CONVERTIBLE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

Go to component -> Navigation circuit, hifi radio with ccc & m-ask (2 of 3) -> GRN WIRE

grn wiring diagram (37 of 75)

AERIAL DIVERSITY (BOTTOM CENTER OF REAR WINDOW) AMPLIFIER (LEFT SIDE OF REAR COMPT) BLK WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM CONTROLLER COUPE CONVERTIBLE DASH) FM AERIAL 2 AERIAL (CONVERTIBLE) (CONVERTIBLE) FM AERIAL 3 (CONVERTIBLE) FUSE 15 FUSE 27 GRN WIRE GRY WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT SIDE TRIM PANEL MID-RANGE SPEAKER LEFT SUBWOOFER NCA WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM REAR WINDOW AERIAL (COUPE) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER RIGHT SUBWOOFER VIO WIRE W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION WHT WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Navigation circuit, hifi radio with ccc & m-ask (3 of 3) -> GRN WIRE

grn wiring diagram (38 of 75)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 (18 TO 21 PINS NOT USED) 22 AERIAL DIGITAL TUNER (CONVERTIBLE) AERIAL DIGITAL TUNER 2 (CONVERTIBLE) BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/ORG WIRE CAR INFORMATION COMPUTER CIC CD CHANGER (LEFT SIDE OF REAR COMPT) CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM COUPE DIGITAL TUNER US (LEFT SIDE OF REAR COMPT) ELECTRONICS JUNCTION BOX FUSE 18 FUSE 19 FUSE FUSE GPS AERIAL GRN WIRE GRY/RED WIRE HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT MICROPHONE MOST-BUS CONNECTOR NCA WIRE ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE ROOF AERIAL (COUPE) RTTI SPLITTER TCU/ULF/ULF- SBX/ULF-SBX-H USB PORT VIDEO MODULE AUX-IN (LEFT SIDE OF CONNECTION REAR COMPT) WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

Go to component -> Navigation circuit, hifi radio with cic (1 of 2) -> GRN WIRE

grn wiring diagram (39 of 75)

AERIAL (CONVERTIBLE) AERIAL DIVERSITY (BOTTOM CENTER OF REAR WINDOW) AMPLIFIER (LEFT SIDE OF REAR COMPT) BLK WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE COUPE COUPE CONVERTIBLE FM AERIAL 2 (CONVERTIBLE) FM AERIAL 3 (CONVERTIBLE) FUSE 15 GRN WIRE GRY WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT SIDE TRIM PANEL MID-RANGE SPEAKER LEFT SUBWOOFER NCA WIRE REAR WINDOW AERIAL (COUPE) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER RIGHT SUBWOOFER SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) SDARS AERIAL W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION WHT WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Navigation circuit, hifi radio with cic (2 of 2) -> GRN WIRE

grn wiring diagram (40 of 75)

BLU WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FUSE GRN WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS NCA WIRE ORG/ WIRE ORG/GRN WIRE PASSENGER'S SEAT ADJUSTMENT SWITCH PASSENGER'S SEAT BACKREST HEATING (IN PASSENGER SEAT BACK) PASSENGER'S SEAT CUSHION HEATING (IN PASSENGER SEAT CUSHION) PASSENGER'S SEAT MODULE (UNDER FRONT PASSENGER'S SEAT) RED WIRE RED/BRN WIRE RED/YEL WIRE RELAY ENERGIZED RELAY ENERGIZED FUSE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE

Go to component -> Passenger"s memory seat circuit (1 of 2) -> GRN WIRE
