Audi TTS 8S facelift (2018-2024) Parking assistant circuit, w/o parallel parking

BLU WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON LEFT FRONT BUMPER COUPLING POINT ON LEFT REAR BUMPER FUSE 32 FUSE PANEL C GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GRY/YEL WIRE HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT REAR CENTER PARKING AID SENSOR LEFT REAR PARKING AID SENSOR ORG/BRN WIRE PARKING AID CONTROL MODULE REAR PARKING AID WARNING BUZZER RED/WHT WIRE RED/YEL WIRE RIGHT REAR CENTER PARKING AID SENSOR RIGHT REAR PARKING AID SENSOR W/ PEDESTRIAN PROTECTION SYSTEM W/O PEDESTRIAN PROTECTION SYSTEM ROADSTER COUPE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

BRN WIRE BRN/RED WIRE BRN/WHT WIRE CENTER SWITCH MODULE FRONT PARKING AID WARNING BUZZER GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GRY/YEL WIRE LEFT FRONT CENTER PARKING AID SENSOR LEFT FRONT PARKING AID SENSOR PARKING AID BUTTON PARKING AID INDICATOR LAMP RED/WHT WIRE RIGHT FRONT CENTER PARKING AID SENSOR RIGHT FRONT PARKING AID SENSOR YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
