Audi TTS 8S facelift (2018-2024) main pressure valve Wiring diagrams
This page contains all the electrical diagrams for the component. main pressure valve, in which he is found in the car Audi TTS 8S facelift (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
main pressure valve wiring diagram (1 of 2)
A/T HYDRAULIC PRESSURE SENSOR 1
A/T HYDRAULIC PRESSURE SENSOR 2
BLK WIRE
BLK/RED WIRE
BLU/GRN WIRE
BRAKE LAMP/ BRAKE PEDAL SWITCH
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
COOLING OIL VALVE
DHHA
DLRA
DUAL-CLUTCH TRANSMISSION MECHATRONIC
ELECTRONICS BOX)
ENGINE CONTROLS SYSTEMS
ENGINE/MOTOR CONTROL MODULE
FUSE 13
FUSE 6
FUSE 7
FUSE PANEL B
GEAR POSITION DISTANCE SENSOR 1
GEAR POSITION DISTANCE SENSOR 2
GEAR POSITION DISTANCE SENSOR 3
GEAR POSITION DISTANCE SENSOR 4
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
MAIN PRESSURE VALVE
ORG/BRN WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SOLENOID VALVE 5
SUB-TRANSMISSION 1 VALVE 1
SUB-TRANSMISSION 1 VALVE 2
SUB-TRANSMISSION 1 VALVE 3
SUB-TRANSMISSION 1 VALVE 4
SUB-TRANSMISSION 2 VALVE 1
SUB-TRANSMISSION 2 VALVE 2
SUB-TRANSMISSION 2 VALVE 3
SUB-TRANSMISSION 2 VALVE 4
TEMPERATURE SENSOR
TRANSMISSION COOLANT VALVE
TRANSMISSION FLUID TEMPERATURE SENSOR
TRANSMISSION INPUT SPEED SENSOR 1
TRANSMISSION INPUT SPEED SENSOR 2
TRANSMISSION OUTPUT SPEED SENSOR
TRANSMISSION OUTPUT SPEED SENSOR 2
WHT/BLU WIRE
Go to component -> 2.0l turbo, a/t circuit (1 of 2) -> MAIN PRESSURE VALVE
main pressure valve wiring diagram (2 of 2)
BLK WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLU/YEL WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRAKE LAMP/ BRAKE PEDAL SWITCH
BRN WIRE
CLUTCH OIL POSITION SENSOR 1
CLUTCH OIL TEMPERATURE SENSOR
CLUTCH PEDAL POSITION SENSOR 2
COMPUTER DATA LINES SYSTEM
COOLING OIL VALVE
DUAL-CLUTCH TRANSMISSION MECHATRONIC (IN TRANSMISSION)
ELECTRONICS BOX)
ENGINE/MOTOR CONTROL MODULE
FUSE 13
FUSE 6
FUSE 9
FUSE PANEL B
FUSE PANEL C
GEAR POSITION DISTANCE SENSOR 1
GEAR POSITION DISTANCE SENSOR 2
GEAR POSITION DISTANCE SENSOR 3
GEAR POSITION DISTANCE SENSOR 4
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 30 POWER SUPPLY RELAY ENERGIZED
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
MAIN PRESSURE VALVE
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
SELECTOR LEVER
SELECTOR LEVER PARK POSITION LOCK SWITCH
SELECTOR LEVER SCALE ILLUMINATION BULB
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT
SHIFT LOCK SOLENOID
STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING WHEEL CONNECTOR
SUB-TRANSMISSION 1 VALVE 1
SUB-TRANSMISSION 1 VALVE 2
SUB-TRANSMISSION 1 VALVE 3
SUB-TRANSMISSION 1 VALVE 4
SUB-TRANSMISSION 2 VALVE 1
SUB-TRANSMISSION 2 VALVE 2
SUB-TRANSMISSION 2 VALVE 3
SUB-TRANSMISSION 2 VALVE 4
TIPTRONIC DOWNSHIFT BUTTON
TIPTRONIC UPSHIFT BUTTON
TRANSMISSION FLUID TEMPERATURE SENSOR
TRANSMISSION INPUT SPEED SENSOR 1
TRANSMISSION INPUT SPEED SENSOR 2
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/GRN WIRE
WHT/BLU WIRE
Go to component -> 2.5l turbo, a/t circuit -> MAIN PRESSURE VALVE
