Audi TTS 8S facelift (2018-2024) door locks, anti-theft, trunk, tailgate, fuel doors systems Wiring diagram
This page shows the only wiring diagram for the component.door locks, anti-theft, trunk, tailgate, fuel doors systems, which is found in the car Audi TTS 8S facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door locks, anti-theft, trunk, tailgate, fuel doors systems (1 of 1)
ACTIVE BODYWORKS SYSTEM
ANTI-THEFT SYSTEM
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DOOR LOCKS, ANTI-THEFT SYSTEMS
DOOR LOCKS, ANTI-THEFT, TRUNK, TAILGATE, FUEL DOORS SYSTEMS
FUSE 24
FUSE 26
FUSE 42
FUSE PANEL C
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RED/BLK WIRE
RED/VIO WIRE
RED/YEL WIRE
SEATS SYSTEM
SUPPLEMENTAL RESTRAINTS, SEATS SYSTEMS
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Vehicle electrical system control module circuit (2 of 2) -> DOOR LOCKS, ANTI-THEFT, TRUNK, TAILGATE, FUEL DOORS SYSTEMS
