Radio circuit, w/ bang & olufson sound for Audi TTS 8S (2014-2018)

ANTENNA ANTENNA AMPLIFIER ANTENNA AMPLIFIER 3 BLK WIRE BLU WIRE BRN WIRE BRN/BLU WIRE COUPE COUPE ROADSTER EXTERNAL AUDIO SOURCE CONNECTION, USB CONNECTION BASEPLATE FUSE 16 FUSE 28 FUSE PANEL C GRN WIRE GRY WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE RADIO ANTENNA REAR VIEW CAMERA SYSTEM CONTROL MODULE RED WIRE RED/BLK WIRE RED/BLU WIRE RIGHT COUPLING POINT ON REAR LID ROADSTER STANDARD USB DISTRIBUTOR W/O TV TUNER YEL WIRE

ACCESS/START AUTHORIZATION CONTROL MODULE ANTENNA AMPLIFIER 2 ANTENNA AMPLIFIER 4 BLK WIRE BLU/GRY WIRE BRN WIRE CELLULAR TELEPHONE AMPLIFIER (RIGHT REAR OF VEHICLE) COUPE COUPE ROADSTER DIGITAL RADIO ANTENNA GPS ANTENNA LEFT COUPLING POINT IN LUGGAGE COMPARTMENT LTE ANTENNA 2 NCA WIRE RADIO ANTENNA 2 RED/BLK WIRE ROADSTER ROOF ANTENNA SATELLITE TUNER ANTENNA STANDARD TELEPHONE ANTENNA TELEPHONE BASEPLATE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/WHT WIRE VIO/YEL WIRE W/O TV TUNER

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/YEL WIRE CENTER SPEAKER CENTER SPEAKER 2 COUPLING POINT ON LEFT FRONT DOOR COUPLING POINT ON RIGHT FRONT DOOR DIGITAL SOUND SYSTEM CONTROL MODULE (UNDER LEFT FRONT SEAT) GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/YEL WIRE LEFT FRONT BASS SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR BASS SPEAKER MOST DATA BUS CIRCUIT NCA WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR BASS SPEAKER VIO WIRE VIO/BLK WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/GRY WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER VOLUME CONTROL FUSE 12 FUSE 4 FUSE PANEL C GRN WIRE GRN/VIO WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 INSTRUMENT CLUSTER CONTROL MODULE INTERIOR MICROPHONE LEFT REAR TREBLE SPEAKER LTE ANTENNA 2 MICROPHONE UNIT (IN FRONT ROOF MODULE) MOST DATA BUS CIRCUIT MULTIMEDIA SYSTEM CONTROL HEAD NCA WIRE ORG/ WIRE ORG/BRN WIRE RED/BLK WIRE RED/GRY WIRE RED/YEL WIRE RIGHT REAR TREBLE SPEAKER TELEPHONE MICROPHONE TV TUNER (IF EQUIPPED) VIO WIRE VIO/BLU WIRE VIO/WHT WIRE WHT WIRE YEL WIRE
