Power windows circuit for Audi TTS 8S (2014-2018)
Power windows circuit
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER DOOR POWER WINDOW CONTROL HEAD
DRIVER POWER WINDOW BUTTON
DRIVER WINDOW REGULATOR MOTOR
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER POWER WINDOW BUTTON
FRONT PASSENGER WINDOW REGULATOR MOTOR
FUSE 25
FUSE 39
FUSE PANEL C
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR COUPLING POINT
ORG/BRN WIRE
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR COUPLING POINT
