Audi TTS 8S (2014-2018) w/ multi-function steering wheel controls Wiring diagram

This page shows the only wiring diagram for the component.w/ multi-function steering wheel controls, which is found in the car Audi TTS 8S (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram w/ multi-function steering wheel controls (1 of 1)

Wiring diagram w/ multi-function steering wheel controls for Audi TTS 8S (2014-2018)

Get access

BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRONICS BOX) FUSE 15 FUSE 9 FUSE PANEL B FUSE PANEL C GRN WIRE HIGH TONE HORN HORN RELAY HOT AT ALL TIMES LOW TONE HORN MULTI-FUNCTION STEERING WHEEL CONTROL MODULE NCA WIRE ORG/BRN WIRE RED/BLU WIRE SIGNAL HORN ACTIVATION SPIRAL SPRING STEERING COLUMN ELECTRONICS CONTROL MODULE STEERING WHEEL) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE W/ MULTI-FUNCTION STEERING WHEEL CONTROLS W/O MULTI-FUNCTION STEERING WHEEL CONTROLS

Go to component: -> Horn circuit -> W/ MULTI-FUNCTION STEERING WHEEL CONTROLS
