Audi TTS 8S (2014-2018) telephone baseplate Wiring diagrams

This page contains all the electrical diagrams for the component. telephone baseplate, in which he is found in the car Audi TTS 8S (2014-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram telephone baseplate (1 of 5)

Wiring diagram telephone baseplate for Audi TTS 8S (2014-2018)

Get access

ACCESS/START AUTHORIZATION CONTROL MODULE ACCESS/START SYSTEM ANTENNA 1 IN VEHICLE INTERIOR ACCESS/START SYSTEM ANTENNA 2 IN VEHICLE INTERIOR ACCESS/START SYSTEM ANTENNA IN LUGGAGE COMPARTMENT ACCESS/START SYSTEM ANTENNA REAR BUMPER ANTI-THEFT IMMOBILIZER READING COIL BLK/RED WIRE BLU WIRE BLU/BLK WIRE BOTTOM COUPLING ON LEFT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER ACCESS/START SYSTEM ANTENNA DRIVER DOOR CONTROL MODULE DRIVER EXTERIOR DOOR HANDLE SWITCH DRIVER EXTERIOR DOOR HANDLE TOUCH SENSOR DRIVER'S SEAT ENGINE CONTROL MODULE FRONT PASSENGER ACCESS/START SYSTEM ANTENNA FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER EXTERIOR DOOR HANDLE SWITCH FRONT PASSENGER EXTERIOR DOOR HANDLE TOUCH SENSOR FUSE 19 FUSE 25 FUSE 39 FUSE PANEL C GRN WIRE GRN/RED WIRE GRY/BLU WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT FRONT DOOR COUPLING POINT ORG/BRN WIRE PASSENGER'S SEAT) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE RIGHT FRONT DOOR COUPLING POINT ROADSTER TELEPHONE BASEPLATE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BLK WIRE VIO/YEL WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE

Go to component: -> Access/start circuit -> TELEPHONE BASEPLATE

Wiring diagram telephone baseplate (2 of 5)

Wiring diagram telephone baseplate for Audi TTS 8S (2014-2018)

Get access

ACCESS/START AUTHORIZATION CONTROL MODULE BLK WIRE BLU/GRY WIRE BRN WIRE CELLULAR TELEPHONE AMPLIFIER (RIGHT REAR OF VEHICLE) COUPE FUSE 16 FUSE PANEL C GPS ANTENNA HOT AT ALL TIMES LEFT COUPLING POINT IN LUGGAGE COMPARTMENT LTE ANTENNA 2 NCA WIRE RED/BLK WIRE ROADSTER ROOF ANTENNA SATELLITE TUNER ANTENNA STANDARD TELEPHONE ANTENNA TELEPHONE BASEPLATE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/WHT WIRE VIO/YEL WIRE

Go to component: -> Navigation circuit (3 of 4) -> TELEPHONE BASEPLATE

Wiring diagram telephone baseplate (3 of 5)

Wiring diagram telephone baseplate for Audi TTS 8S (2014-2018)

Get access

AIR QUALITY SENSOR, HUMIDITY SENSOR IN FRESH AIR INTAKE DUCT BLK WIRE BLU WIRE BLU/RED WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR CELLULAR TELEPHONE AMPLIFIER CHIP CARD READER CONTROL MODULE COUPE ROADSTER DIAGNOSTIC CONNECTION ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE FROM FUSE 33 (DIAGRAM 4 OF 6) FROM MAIN FUSE CARRIER (DIAGRAM 1 OF 6) FRONT/ CENTER CONSOLE CONTROL HEAD FUSE 15 FUSE 16 FUSE 17 FUSE 18 FUSE 3 FUSE 35 FUSE 36 FUSE 37 FUSE 47 FUSE 48 FUSE 49 FUSE 50 FUSE PANEL B ELECTRONICS BOX FUSE PANEL C GRN WIRE GRY WIRE HEADLAMP RANGE CONTROL MODULE INSTRUMENT CLUSTER CONTROL MODULE INTERIOR REAR VIEW MIRROR LEFT COUPLING POINT ON REAR LID LEFT FRONT HEADLAMP N/R REAR VIEW CAMERA SYSTEM CONTROL MODULE RED WIRE RIGHT FRONT HEADLAMP ROADSTER SEAT BELT MICROPHONE CONTROL MODULE STARTER RELAY 1 STARTER RELAY 2 TELEPHONE BASEPLATE TO ABS CONTROL CONTROL MODULE (DIAGRAM 2 OF 6) TO FUSE 20 (DIAGRAM 6 OF 6) TV TUNER VEHICLE POSITIONING SYSTEM INTERFACE CONTROL MODULE VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Power distribution circuit (5 of 6) -> TELEPHONE BASEPLATE

Wiring diagram telephone baseplate (4 of 5)

Wiring diagram telephone baseplate for Audi TTS 8S (2014-2018)

Get access

ACCESS/START AUTHORIZATION CONTROL MODULE ANTENNA AMPLIFIER 2 ANTENNA AMPLIFIER 4 BLK WIRE BLU/GRY WIRE BRN WIRE CELLULAR TELEPHONE AMPLIFIER (RIGHT REAR OF VEHICLE) COUPE COUPE ROADSTER DIGITAL RADIO ANTENNA GPS ANTENNA LEFT COUPLING POINT IN LUGGAGE COMPARTMENT LTE ANTENNA 2 NCA WIRE RADIO ANTENNA 2 RED/BLK WIRE ROADSTER ROOF ANTENNA SATELLITE TUNER ANTENNA STANDARD TELEPHONE ANTENNA TELEPHONE BASEPLATE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/WHT WIRE VIO/YEL WIRE W/O TV TUNER

Go to component: -> Radio circuit, w/ bang & olufson sound (2 of 4) -> TELEPHONE BASEPLATE

Wiring diagram telephone baseplate (5 of 5)

Wiring diagram telephone baseplate for Audi TTS 8S (2014-2018)

Get access

ACCESS/START AUTHORIZATION CONTROL MODULE BLK WIRE BLU/GRY WIRE BRN WIRE CELLULAR TELEPHONE AMPLIFIER (RIGHT REAR OF VEHICLE) COUPE FUSE 16 FUSE PANEL C GPS ANTENNA HOT AT ALL TIMES LEFT COUPLING POINT IN LUGGAGE COMPARTMENT LTE ANTENNA 2 NCA WIRE RED/BLK WIRE ROADSTER ROOF ANTENNA SATELLITE TUNER ANTENNA STANDARD TELEPHONE ANTENNA TELEPHONE BASEPLATE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/WHT WIRE VIO/YEL WIRE

Go to component: -> Radio circuit, w/ navigation (3 of 4) -> TELEPHONE BASEPLATE
