Audi TTS 8S (2014-2018) support adjustment Wiring diagram
This page shows the only wiring diagram for the component.support adjustment, which is found in the car Audi TTS 8S (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram support adjustment (1 of 1)
ANTENNA AMPLIFIER SHIELD
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CELLULAR TELEPHONE AMPLIFIER, REAR VIEW CAMERA SYSTEM CONTROL MODULE (COUPE)
DRIVER MULTI- CONTOUR SEAT CONTROL MODULE
DRIVER SEAT ADJUSTMENT CONTROL HEAD
DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH (W/O LUMBAR),
DRIVER SEAT SWITCH MODULE
DRIVER THORAX AIRBAG IGNITER
FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD (W/ MULTI-CONTOUR SEATS)
FRONT PASSENGER SEAT LUMBAR
GRY WIRE
LEFT NECK HEATING FAN, LEFT NECK HEATING CONTROL MODULE
PASSENGER OCCUPANT DETECTION
SUPPORT ADJUSTMENT
SYSTEM CONTROL MODULE (W/ PASSIVE OCCUPANT DETECTION SYSTEM)
Go to component: -> Ground distribution circuit (2 of 3) -> SUPPORT ADJUSTMENT
