Audi TTS 8S (2014-2018) selector lever park position lock switch Wiring diagrams

This page contains all the electrical diagrams for the component. selector lever park position lock switch, in which he is found in the car Audi TTS 8S (2014-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram selector lever park position lock switch (1 of 2)

Wiring diagram selector lever park position lock switch for Audi TTS 8S (2014-2018)

Get access

BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 6 FUSE PANEL C GRN WIRE GRN/RED WIRE GRY/BLU WIRE GRY/GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT MULTI-FUNCTION STEERING WHEEL BUTTONS MULTI-FUNCTION STEERING WHEEL CONTROL MODULE NCA WIRE ORG/BRN WIRE POWER DISTRIBUTION SYSTEM RIGHT MULTI-FUNCTION STEERING WHEEL BUTTONS SELECTOR LEVER SELECTOR LEVER PARK POSITION LOCK SWITCH SELECTOR LEVER SCALE ILLUMINATION BULB SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT SHIFT LOCK SOLENOID STEERING COLUMN ELECTRONICS CONTROL MODULE STEERING WHEEL) TIPTRONIC DOWNSHIFT BUTTON TIPTRONIC UPSHIFT BUTTON TRANSMISSION NEUTRAL POSITION SENSOR WHT/BLU WIRE YEL/BRN WIRE YEL/GRY WIRE

Go to component: -> A/t circuit (2 of 2) -> SELECTOR LEVER PARK POSITION LOCK SWITCH

Wiring diagram selector lever park position lock switch (2 of 2)

Wiring diagram selector lever park position lock switch for Audi TTS 8S (2014-2018)

Get access

BLK WIRE BLK/RED WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRAKE LAMP SWITCH, BRAKE PEDAL SWITCH BRN WIRE BULB COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM DSG TRANSMISSION MECHATRONIC ELECTRONIC BOX ENGINE CONTROL MODULE FUSE 6 FUSE PANEL B FUSE PANEL C GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRY/BLU WIRE GRY/GRN WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED ILLUMINATION INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE INTERIOR LEVER SCALE LIGHTS SYSTEM NCA WIRE ORG/BRN WIRE POWER DISTRIBUTION SYSTEM SELECTOR SELECTOR LEVER SELECTOR LEVER PARK POSITION LOCK SWITCH SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT SHIFT LOCK SOLENOID STEERING COLUMN ELECTRONICS CONTROL MODULE SYSTEM VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT/BLU WIRE

Go to component: -> Shift interlock circuit -> SELECTOR LEVER PARK POSITION LOCK SWITCH
