Audi TTS 8S (2014-2018) rear spoiler Wiring diagram
This page shows the only wiring diagram for the component.rear spoiler, which is found in the car Audi TTS 8S (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear spoiler (1 of 1)
BLK/RED WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
BRN/BLK WIRE
CENTER SWITCH MODULE IN INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
COUPE
FUSE 26
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
LEFT COUPLING POINT IN LUGGAGE COMPARTMENT
ORG/BRN WIRE
REAR SPOILER
REAR SPOILER ADJUSTMENT INDICATOR LAMP
REAR SPOILER ADJUSTMENT SWITCH
REAR SPOILER MOTOR
REAR SPOILER STOP SWITCH 1
REAR SPOILER STOP SWITCH 2
RED/YEL WIRE
ROADSTER
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT/GRY WIRE
Go to component: -> Active bodyworks circuit -> REAR SPOILER
