Audi TTS 8S (2014-2018) left rear abs wheel speed sensor Wiring diagram
This page shows the only wiring diagram for the component.left rear abs wheel speed sensor, which is found in the car Audi TTS 8S (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear abs wheel speed sensor (1 of 1)
ASR/ESP BUTTON
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU/RED WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRAKE FLUID LEVEL WARNING SWITCH
BRAKE LAMP SWITCH, BRAKE PEDAL SWITCH
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DSG TRANSMISSION MECHATRONIC
ELECTRONICS BOX)
ENGINE CONTROL MODULE
FUSE 35
FUSE 6
FUSE PANEL B
FUSE PANEL C
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY/BLK WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT ABS WHEEL SPEED SENSOR
LEFT PARKING BRAKE MOTOR
LEFT REAR ABS WHEEL SPEED SENSOR
ORG/BRN WIRE
RED/BLU WIRE
RIGHT FRONT ABS WHEEL SPEED SENSOR
RIGHT PARKING BRAKE MOTOR
RIGHT REAR ABS WHEEL SPEED SENSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
Go to component: -> Anti-lock brakes circuit (2 of 2) -> LEFT REAR ABS WHEEL SPEED SENSOR
