Audi TTS 8S (2014-2018) left hid headlamp bulb Wiring diagram
This page shows the only wiring diagram for the component.left hid headlamp bulb, which is found in the car Audi TTS 8S (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left hid headlamp bulb (1 of 1)
AUTOMATIC HIGH BEAM ASSIST CONTROL MODULE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/RED WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE 31
FUSE 35
FUSE 8
FUSE PANEL C
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INSIDE REAR VIEW MIRROR
INSTRUMENT CLUSTER CONTROL MODULE
INTERIOR REAR VIEW MIRROR
LEFT DAYTIME RUNNING LAMP, POSITION LAMP CONTROL MODULE
LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
LEFT FRONT HEADLAMP
LEFT FRONT SIDE MARKER LAMP BULB
LEFT FRONT TURN SIGNAL BULB
LEFT HEADLAMP BEAM ADJUSTMENT MOTOR
LEFT HID HEADLAMP BULB
LEFT LOW BEAM HEADLAMP REFLECTOR MOTOR
LEFT STATIONARY CORNERING LAMP
LIGHT SWITCH
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RAIN/LIGHT RECOGNITION SENSOR, HUMIDITY SENSOR
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/YEL WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
Go to component: -> Headlights circuit, w/ hid (1 of 2) -> LEFT HID HEADLAMP BULB
