Audi TTS 8S (2014-2018) front passenger multi-contour seat compressor Wiring diagram

This page shows the only wiring diagram for the component.front passenger multi-contour seat compressor, which is found in the car Audi TTS 8S (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram front passenger multi-contour seat compressor (1 of 1)

Wiring diagram front passenger multi-contour seat compressor for Audi TTS 8S (2014-2018)

Get access

BRN WIRE BRN/GRN WIRE BRN/WHT WIRE DRIVER MULTI- CONTOUR SEAT CONTROL MODULE DRIVER MULTI-CONTOUR SEAT COMPRESSOR DRIVER SEAT SWITCH MODULE FRONT PASSENGER MULTI-CONTOUR SEAT COMPRESSOR FRONT PASSENGER MULTI-CONTOUR SEAT CONTROL MODULE FRONT PASSENGER SEAT SWITCH MODULE FUSE 20 FUSE PANEL C GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES LEFT FRONT SEAT COUPLING STATION NECK WARMER CIRCUIT RED/GRN WIRE RIGHT FRONT SEAT COUPLING STATION VIO/WHT WIRE YEL/BLU WIRE

Go to component: -> Multi contour seat circuit -> FRONT PASSENGER MULTI-CONTOUR SEAT COMPRESSOR
