Audi TTS 8S (2014-2018) front passenger backrest stop switch Wiring diagram

This page shows the only wiring diagram for the component.front passenger backrest stop switch, which is found in the car Audi TTS 8S (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram front passenger backrest stop switch (1 of 1)

Wiring diagram front passenger backrest stop switch for Audi TTS 8S (2014-2018)

Get access

ANGLE BACKREST BLK/RED WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COUPE FRONT PASSENGER BACKREST ADJUSTMENT MOTOR FRONT PASSENGER BACKREST STOP SWITCH FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD FRONT PASSENGER SEAT ADJUSTMENT MOTOR FRONT PASSENGER SEAT FORWARD/ ADJUSTMENT MOTOR FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR FWD/BWD HEIGHT HOT AT ALL TIMES RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT SEAT COUPLING STATION W/O MULTI-CONTOUR SEATS W/ MULTI-CONTOUR SEATS WHT/BLK WIRE

Go to component: -> Power seats circuit (3 of 3) -> FRONT PASSENGER BACKREST STOP SWITCH
