Audi TTS 8S (2014-2018) driving profile selection button Wiring diagram
This page shows the only wiring diagram for the component.driving profile selection button, which is found in the car Audi TTS 8S (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driving profile selection button (1 of 1)
BLK WIRE
BLU WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
BRN/GRN WIRE
CENTER SWITCH MODULE IN INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
DAMPING ADJUSTMENT BUTTON
DRIVING PROFILE SELECTION BUTTON
FUSE 9
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT LEVEL CONTROL SYSTEM SENSOR
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
ORG/BRN WIRE
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RIGHT FRONT LEVEL CONTROL SYSTEM SENSOR
STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING WHEEL)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRY WIRE
Go to component: -> Electronic suspension circuit (2 of 2) -> DRIVING PROFILE SELECTION BUTTON
