Audi TTS 8S (2014-2018) driver seat heating element, temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.driver seat heating element, temperature sensor, which is found in the car Audi TTS 8S (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver seat heating element, temperature sensor (1 of 1)
BLK/RED WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CLIMATRONIC CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVER BACKREST HEATING ELEMENT
DRIVER SEAT BOLSTER HEATING ELEMENT
DRIVER SEAT HEATING ELEMENT, TEMPERATURE SENSOR
FRONT PASSENGER BACKREST HEATING ELEMENT
FRONT PASSENGER SEAT BOLSTER HEATING ELEMENT
FRONT PASSENGER SEAT HEATING ELEMENT, TEMPERATURE SENSOR
FUSE 26
FUSE PANEL C
GRN WIRE
GRN/BRN WIRE
GRY WIRE
HEATED DRIVER SEAT EXTENSION
HEATED FRONT PASSENGER SEAT EXTENSION
HOT AT ALL TIMES
LEFT
LEFT FRONT SEAT COUPLING STATION
ORG/BRN WIRE
PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT
RIGHT FRONT SEAT COUPLING STATION
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
W/ AUXILIARY HEATER
WHT WIRE
WHT/VIO WIRE
WHT/YEL WIRE
Go to component: -> Heated seats circuit -> DRIVER SEAT HEATING ELEMENT, TEMPERATURE SENSOR
