Audi TTS 8S (2014-2018) convertible top latch open & close switch Wiring diagram

This page shows the only wiring diagram for the component.convertible top latch open & close switch, which is found in the car Audi TTS 8S (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram convertible top latch open & close switch (1 of 1)

Wiring diagram convertible top latch open & close switch for Audi TTS 8S (2014-2018)

Get access

BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE CONVERTIBLE TOP LATCH OPEN & CLOSE SWITCH CONVERTIBLE TOP LOCKING MOTOR CONVERTIBLE TOP MOTOR CONVERTIBLE TOP MOTOR 2 CONVERTIBLE TOP OPERATION SWITCH CONVERTIBLE WIND DEFLECTOR SWITCH GRN WIRE GRY/BLU WIRE VIO WIRE WHT/BRN WIRE YEL WIRE YEL/BLU WIRE YEL/VIO WIRE YEL/WHT WIRE

Go to component: -> Power top/sunroof circuit (2 of 2) -> CONVERTIBLE TOP LATCH OPEN & CLOSE SWITCH
