Starting circuit, a/t without direct shift for Audi TT 8N facelift (2003-2006)
Starting circuit, a/t without direct shift
13-FOLD RELAY PANEL (BENEATH LEFT SIDE OF DASH)
BATTERY
BLK WIRE
BRN WIRE
GRN WIRE
GRY WIRE
IGNITION SWITCH
MAIN FUSE BOX (ON TOP OF BATTERY, ON LEFT SIDE OF ENGINE COMPT) FUSE 134
MICRO CENTRAL ELECTRIC PANEL (BENEATH LEFT SIDE OF DASH)
MULTI-FUNCTION TRANSMISSION RANGE SWITCH
OFF
P/N
RED WIRE
STARTER
STARTING INTERLOCK RELAY
