Back-up lamps circuit for Audi TT 8N facelift (2003-2006)
Back-up lamps circuit
13-FOLD RELAY PANEL (BENEATH LEFT SIDE OF DASH)
BACK- UP LIGHT
BACK-UP LIGHT RELAY
BACK-UP LIGHT SWITCH (ON TOP OF TRANSMISSION, NEAR STARTER MOTOR)
BLK/GRN WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
DIRECT SHIFT GEARBOX (DSG)
FUSE 7
FUSE PANEL (BEHIND LEFT END OF DASH)
GRN/YEL WIRE
HOT IN RUN OR START
LEFT TAILLIGHT ASSEMBLY BACK- UP LIGHT
NAVIGATION CONTROL MODULE
RED/GRN WIRE
RIGHT TAILLIGHT ASSEMBLY
W/ DIRECT SHIFT GEARBOX
W/O DIRECT SHIFT GEARBOX
