Audi TT 8N facelift (2003-2006) tiptronic switch Wiring diagrams
This page contains all the electrical diagrams for the component. tiptronic switch, in which he is found in the car Audi TT 8N facelift (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram tiptronic switch (1 of 3)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
DIRECT SHIFT GEARBOX (DSG) MECHATRONIC
DOWN- SHIFT (LEFT) SWITCH
FUSE 12
FUSE 31
FUSE 7
FUSE HOLDER (LEFT END OF DASH) FUSE 11
GRN/BLU WIRE
GRN/BRN WIRE
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
ILLUMINATION FOR SELECTOR LEVER SCALE
INSTRUMENT CLUSTER
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/BRN WIRE
RED WIRE
RED/BRN WIRE
RED/WHT WIRE
SHIFT LOCK SOLENOID
STARTING SYSTEM (INTERLOCK RELAY) EXTERIOR LIGHTS SYSTEM (BACKUP)
STEERING WHEEL CONTROL UNIT
TIPTRONIC SWITCH
UP- SHIFT (RIGHT) SWITCH
VIO WIRE
VIO/BRN WIRE
VIO/RED WIRE
W-BOX (IN ENGINE COMPT)
WHT WIRE
Go to component -> A/t circuit, with direct shift -> TIPTRONIC SWITCH
Wiring diagram tiptronic switch (2 of 3)
BLK WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
EXTERIOR LIGHTS SYSTEM (BACKUP)
FLUID TEMPERATURE SENSOR
FUSE 15
FUSE 31
FUSE HOLDER (LEFT END OF DASH) FUSE 7
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER
LEFT SWITCH PACK
MULTIFUNCTION TRANSMISSION RANGE SWITCH (LEFT SIDE OF TRANSMISSION)
ORG/BLK WIRE
ORG/BRN WIRE
RED WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT SWITCH PACK
SHIFT LOCK SOLENOID
SOLENOID VALVES
STEERING WHEEL CONTROL UNIT
TIPTRONIC SWITCH
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION SPEED SENSOR
TRANSMISSION VALVE BODY
VEHICLE SPEED SENSOR HYDRAULIC PRESSURE SENDERS
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> A/t circuit, without direct shift -> TIPTRONIC SWITCH
Wiring diagram tiptronic switch (3 of 3)
Go to component -> Shift interlock circuit -> TIPTRONIC SWITCH
