Audi TT 8N facelift (2003-2006) remote rear lid unlock switch central locking control module Wiring diagram
This page shows the only wiring diagram for the component.remote rear lid unlock switch central locking control module, which is found in the car Audi TT 8N facelift (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram remote rear lid unlock switch central locking control module (1 of 1)
A/C CONTROL HEAD
AMPLIFIER (BOSE) LEFT REAR WOOFER/ AMPLIFIER (W/O BOSE) (COUPE)
ANTI-THEFT WARNING ULTRA SOUND SENSOR (COUPE)
BLK WIRE
BLU WIRE
BRAKE LIGHT SWITCH
BRN WIRE
CENTER REAR WOOFER/ AMPLIFIER (W/O BOSE) (ROADSTER) RADIO
CENTRAL LOCKING CONTROL MODULE
CIGARETTE LIGHTER
DATA LINK CONNECTOR
DUAL HORN RELAY
EMERGENCY FLASHER SWITCH
FRESH AIR BLOWER
FROM MICRO CENTRAL ELECTRIC PANEL (DIAGRAM 1 OF 4)
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 2
FUSE 24
FUSE 25
FUSE 26
FUSE 27
FUSE 38
FUSE 39
FUSE 40
FUSE 41
FUSE 42
FUSE PANEL (ON LEFT END OF DASH)
GRN WIRE
GRY WIRE
MICRO CENTRAL ELECTRIC PANEL (BENEATH LEFT SIDE OF DASH)
NAVIGATION CONTROL MODULE TIPTRONIC SWITCH (DIRECT SHIFT GEARBOX)
OPERATING ELECTRONICS, TELEPHONE CONTROL MODULE (W/ TELEPHONE PREPARATION)
PASSENGER COMPARTMENT MONITORING SWITCH
REAR WINDOW DEFOGGER SWITCH
RED WIRE
REMOTE REAR LID UNLOCK SWITCH CENTRAL LOCKING CONTROL MODULE
SATELLITE RADIO (2005)
STEERING ANGLE SENSOR INSTRUMENT CLUSTER
SUPPRESOR FILTER
TRANSMISSION CONTROL MODULE
VIO WIRE
WHT WIRE
WIND DEFLECTOR CONTROL MODULE
WIND DEFLECTOR SWITCH
WINDSHIELD WIPER/WASHER SWITCH
WIPER/WASHER INTERMITTENT RELAY
YEL WIRE
Go to component -> Power distribution circuit (3 of 4) -> REMOTE REAR LID UNLOCK SWITCH CENTRAL LOCKING CONTROL MODULE
