Audi TT 8N facelift (2003-2006) multifunction transmission range switch (left side of transmission) wiring diagram
This page shows the only wiring diagram for the component.multifunction transmission range switch (left side of transmission), which is found in the car Audi TT 8N facelift (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
multifunction transmission range switch (left side of transmission) wiring diagram (1 of 1)
BLK WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
EXTERIOR LIGHTS SYSTEM (BACKUP)
FLUID TEMPERATURE SENSOR
FUSE 15
FUSE 31
FUSE HOLDER (LEFT END OF DASH) FUSE 7
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER
LEFT SWITCH PACK
MULTIFUNCTION TRANSMISSION RANGE SWITCH (LEFT SIDE OF TRANSMISSION)
ORG/BLK WIRE
ORG/BRN WIRE
RED WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT SWITCH PACK
SHIFT LOCK SOLENOID
SOLENOID VALVES
STEERING WHEEL CONTROL UNIT
TIPTRONIC SWITCH
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION SPEED SENSOR
TRANSMISSION VALVE BODY
VEHICLE SPEED SENSOR HYDRAULIC PRESSURE SENDERS
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> A/t circuit, without direct shift -> MULTIFUNCTION TRANSMISSION RANGE SWITCH (LEFT SIDE OF TRANSMISSION)
