Audi TT 8N facelift (2003-2006) mechatronic direct shift gearbox Wiring diagram

13-FOLD RELAY PANEL (BENEATH LEFT SIDE OF DASH) ABS CONTROL MODULE BATTERY BLK WIRE BRAKE BOOSTER RELAY BRN WIRE CONVERTIBLE TOP FUSE (ATTACHED TO MICRO CENTRAL ELECTRIC PANEL) FUSE CONVERTIBLE TOP HYDRAULIC PUMP RELAY COOLANT FAN CONTROL MODULE COOLANT FAN CONTROL THERMAL SWITCH DRIVER'S SIDE HEATED OUTSIDE MIRROR DUAL HORN RELAY FUEL PUMP RELAY FUSE 1 FUSE 131 FUSE 132 FUSE 133 FUSE 134 FUSE 138 FUSE 16 FUSE 44 FUSE 162 FUSE 163 FUSE 164 FUSE 37 FUSE 79 FUSE PANEL (ON LEFT END OF DASH) FUSE PANEL (ON LEFT END OF DASH) FUSE 33 GENERATOR GRN WIRE GRY WIRE HEADLIGHT DIMMER/ FLASHER SWITCH LEFT FRONT POWER WINDOW CONTROL MODULE LEFT WASHER NOZZLE HEATER, RIGHT WASHER NOZZLE HEATER LIGHT SWITCH LOAD REDUCTION RELAY MAIN FUSE BOX (ON TOP OF BATTERY, LEFT SIDE OF ENG COMPT) MECHATRONIC DIRECT SHIFT GEARBOX MICRO CENTRAL ELECTRIC PANEL (BEHIND LEFT SIDE OF DASH) MICRO CENTRAL ELECTRIC PANEL (BENEATH LEFT SIDE OF DASH) MOTRONIC ENGINE CONTROL MODULE (ECM) MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY PASSENGER'S HEATED SEAT ADJUSTER DRIVER'S HEATED SEAT ADJUSTER PASSENGER'S SIDE HEATED OUTSIDE MIRROR REAR WINDOW DEFOGGER RELAY RED WIRE RED/BLK WIRE RED/BRN WIRE RED/GRY WIRE RIGHT FRONT POWER WINDOW CONTROL MODULE ROADSTER ONLY SECONDARY AIR INJECTION PUMP RELAY STARTER STARTING INTERLOCK RELAY (A/T) TO FUSE PANEL (DIAGRAM 3 OF 4) TO IGNITION SWITCH (DIAGRAM 2 OF 4) W-BOX (IN ENGINE COMPT) W-BOX (IN ENGINE COMPT) FUSE 7 W/ HEADLIGHT WASHER WHT WIRE WIPER/WASHER INTERMITTENT RELAY YEL WIRE
