Audi TT 8N facelift (2003-2006) low beam Wiring diagrams
This page contains all the electrical diagrams for the component. low beam, in which he is found in the car Audi TT 8N facelift (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
low beam wiring diagram (1 of 2)
13-FOLD RELAY PANEL (BENEATH LEFT SIDE OF DASH)
BLK/RED WIRE
BLK/WHT WIRE
BRN WIRE
FOG LIGHT
FOG LIGHT RELAY
FOG LIGHT SWITCH OFF
FOGLIGHT INDICATOR
FOGLIGHT SWITCH LIGHT
FRONT
FTP
FUSE 18
FUSE 19 FUSE 17
FUSE 20 FUSE 21
FUSE 3
FUSE 36
FUSE PANEL (LEFT END OF DASH)
GRN/GRY WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HEAD
HEADLIGHT DIMMER/ FLASHER SWITCH
HEADLIGHT SWITCH LIGHT
HIGH BEAM
HIGH BEAM IND
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT CLUSTER
LAMP CONTROL MODULE (ON 13-FOLD RELAY PANEL, BENEATH LEFT SIDE OF DASH)
LEFT FRONT HEADLIGHT/ PARK LIGHT ASSEMBLY
LIGHT SWITCH/ FOGLIGHT SWITCH
LOW BEAM
MAIN FUSE BOX (LEFT SIDE OF ENGINE COMPT, TOP OF BATTERY) FUSE 132
MICRO CENTRAL ELECTRIC PANEL (BENEATH LEFT SIDE OF DASH)
OFF
OFF LIGHT SWITCH HEAD
PARK
REAR
REAR FOGLIGHT INDICATOR
RED WIRE
RIGHT FRONT HEADLIGHT/ PARK LIGHT ASSEMBLY
RUN WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Headlamps circuit, with drl -> LOW BEAM
low beam wiring diagram (2 of 2)
13-FOLD RELAY PANEL (BENEATH LEFT SIDE OF DASH)
BLK/RED WIRE
BLK/WHT WIRE
BRN WIRE
FOG LIGHT
FOG LIGHT RELAY
FOG LIGHT SWITCH OFF
FOGLIGHT INDICATOR
FOGLIGHT SWITCH LIGHT
FRONT
FTP
FUSE 18
FUSE 19
FUSE 20 FUSE 21
FUSE 3
FUSE 36
FUSE PANEL (LEFT END OF DASH)
GRN/GRY WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HEAD
HEADLIGHT DIMMER/ FLASHER SWITCH
HEADLIGHT SWITCH LIGHT
HIGH BEAM
HIGH BEAM IND
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT CLUSTER
LAMP CONTROL MODULE (ON 13-FOLD RELAY PANEL, BENEATH LEFT SIDE OF DASH)
LEFT FRONT HEADLIGHT/ PARK LIGHT ASSEMBLY
LIGHT SWITCH/ FOGLIGHT SWITCH
LOW BEAM
MAIN FUSE BOX (LEFT SIDE OF ENGINE COMPT, TOP OF BATTERY) FUSE 132
MICRO CENTRAL ELECTRIC PANEL (BENEATH LEFT SIDE OF DASH)
OFF
OFF LIGHT SWITCH HEAD
PARK
REAR
REAR FOGLIGHT INDICATOR
RED WIRE
RIGHT FRONT HEADLIGHT/ PARK LIGHT ASSEMBLY
RUN WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Headlamps circuit, without drl, without high intensity gas discharge headlights -> LOW BEAM
