Audi TT 8N facelift (2003-2006) illumination for selector lever scale Wiring diagram
This page shows the only wiring diagram for the component.illumination for selector lever scale, which is found in the car Audi TT 8N facelift (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram illumination for selector lever scale (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
DIRECT SHIFT GEARBOX (DSG) MECHATRONIC
DOWN- SHIFT (LEFT) SWITCH
FUSE 12
FUSE 31
FUSE 7
FUSE HOLDER (LEFT END OF DASH) FUSE 11
GRN/BLU WIRE
GRN/BRN WIRE
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
ILLUMINATION FOR SELECTOR LEVER SCALE
INSTRUMENT CLUSTER
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/BRN WIRE
RED WIRE
RED/BRN WIRE
RED/WHT WIRE
SHIFT LOCK SOLENOID
STARTING SYSTEM (INTERLOCK RELAY) EXTERIOR LIGHTS SYSTEM (BACKUP)
STEERING WHEEL CONTROL UNIT
TIPTRONIC SWITCH
UP- SHIFT (RIGHT) SWITCH
VIO WIRE
VIO/BRN WIRE
VIO/RED WIRE
W-BOX (IN ENGINE COMPT)
WHT WIRE
Go to component -> A/t circuit, with direct shift -> ILLUMINATION FOR SELECTOR LEVER SCALE
