Audi TT 8N facelift (2003-2006) fog light switch headlight switch light Wiring diagram
This page shows the only wiring diagram for the component.fog light switch headlight switch light, which is found in the car Audi TT 8N facelift (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fog light switch headlight switch light (1 of 1)
A/C CONTROL HEAD
ASHTRAY LIGHT
ASR/ESP BUTTON
BLU WIRE
BRN WIRE
CIGARETTE LIGHTER LIGHT
COMBINATION PROCESSOR
CONVERTIBLE TOP SWITCH
DRIVER SIDE INTERIOR LOCK SWITCH FRONT INTERIOR LIGHT
FOG LIGHT SWITCH HEADLIGHT SWITCH LIGHT
FUNCTION SELECTOR SWITCH 2
FUSE 22
FUSE 23
FUSE PANEL (ON LEFT END OF DASH)
GARAGE DOOR OPENER CONTROL HEAD
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
HEAD OFF PARK
HEATED SEAT ADJUSTERS
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL LIGHT DIMMER SWITCH
LEFT SWITCH
LIGHT SWITCH
MIRROR ADJUSTMENT SWITCH
NCA WIRE
OPERATING ELECTRONICS, TELEPHONE CONTROL MODULE (W/ TELEPHONE PREPARATION)
PASSENGER AIR BAG OFF KEY SWITCH
PASSENGER COMPARTMENT MONITORING SWITCH
RADIO
REAR WINDOW DEFOGGER SWITCH
REMOTE FUEL TANK DOOR SWITCH
REMOTE REAR LID UNLOCK SWITCH
RIGHT SWITCH
STEERING WHEEL TIPTRONIC SWITCH
WHT WIRE
WIND DEFLECTOR SWITCH (CABRIO)
Go to component -> Instrument illumination circuit -> FOG LIGHT SWITCH HEADLIGHT SWITCH LIGHT
