Audi TT 8N facelift (2003-2006) driver's side heated outside mirror Wiring diagrams
This page contains all the electrical diagrams for the component. driver's side heated outside mirror, in which he is found in the car Audi TT 8N facelift (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
driver's side heated outside mirror wiring diagram (1 of 3)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
DRIVER'S SIDE HEATED OUTSIDE MIRROR
FUSE
FUSE PANEL (ON LEFT END OF DASH)
GRN WIRE
GRY WIRE
HEATED REAR WINDOW
HOT AT ALL TIMES
HOT IN
LOAD REDUCTION RELAY
MICRO CENTRAL ELECTRIC PANEL (BENEATH LEFT SIDE OF DASH)
PASSENGER'S SIDE HEATED OUTSIDE MIRROR
REAR WINDOW DEFOGGER SWITCH
REAR WINDOW DEFOGGER/ WINDOW ANTENNA
RUN WIRE
SOLID STATE
SOUND SYSTEM
W/ WINDOW ANTENNA
W/O WINDOW ANTENNA
WHT WIRE
WINDSHIELD ANTENNA SUPPRESSION FILTER
WIPER/ WASHER SYSTEM
Go to component -> Defoggers circuit, coupe -> DRIVER'S SIDE HEATED OUTSIDE MIRROR
driver's side heated outside mirror wiring diagram (2 of 3)
13-FOLD RELAY PANEL (BENEATH LEFT SIDE OF DASH)
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
CONVERTIBLE TOP OPEN POSITION SWITCH
DRIVER'S SIDE HEATED OUTSIDE MIRROR
FUSE
FUSE PANEL (ON LEFT END OF DASH)
GRN WIRE
GRY WIRE
HARD TOP SOFT TOP
HEATED REAR WINDOW HEATED REAR WINDOW
HOT AT ALL TIMES
HOT IN
IGNITION SWITCH
LOAD REDUCTION RELAY
MICRO CENTRAL ELECTRIC PANEL (BENEATH LEFT SIDE OF DASH)
OFF
PASSENGER'S SIDE HEATED OUTSIDE MIRROR
POWER TOPS SYSTEM
REAR WINDOW DEFOGGER RELAY
REAR WINDOW DEFOGGER SWITCH
RUN WIRE
SOLID STATE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WIPER/ WASHER SYSTEM
Go to component -> Defoggers circuit, roadster -> DRIVER'S SIDE HEATED OUTSIDE MIRROR
driver's side heated outside mirror wiring diagram (3 of 3)
13-FOLD RELAY PANEL (BENEATH LEFT SIDE OF DASH)
ABS CONTROL MODULE
BATTERY
BLK WIRE
BRAKE BOOSTER RELAY
BRN WIRE
CONVERTIBLE TOP FUSE (ATTACHED TO MICRO CENTRAL ELECTRIC PANEL) FUSE
CONVERTIBLE TOP HYDRAULIC PUMP RELAY
COOLANT FAN CONTROL MODULE
COOLANT FAN CONTROL THERMAL SWITCH
DRIVER'S SIDE HEATED OUTSIDE MIRROR
DUAL HORN RELAY
FUEL PUMP RELAY
FUSE 1
FUSE 131
FUSE 132
FUSE 133
FUSE 134
FUSE 138
FUSE 16 FUSE 44
FUSE 162
FUSE 163
FUSE 164
FUSE 37
FUSE 79
FUSE PANEL (ON LEFT END OF DASH)
FUSE PANEL (ON LEFT END OF DASH) FUSE 33
GENERATOR
GRN WIRE
GRY WIRE
HEADLIGHT DIMMER/ FLASHER SWITCH
LEFT FRONT POWER WINDOW CONTROL MODULE
LEFT WASHER NOZZLE HEATER, RIGHT WASHER NOZZLE HEATER
LIGHT SWITCH
LOAD REDUCTION RELAY
MAIN FUSE BOX (ON TOP OF BATTERY, LEFT SIDE OF ENG COMPT)
MECHATRONIC DIRECT SHIFT GEARBOX
MICRO CENTRAL ELECTRIC PANEL (BEHIND LEFT SIDE OF DASH)
MICRO CENTRAL ELECTRIC PANEL (BENEATH LEFT SIDE OF DASH)
MOTRONIC ENGINE CONTROL MODULE (ECM)
MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY
PASSENGER'S HEATED SEAT ADJUSTER DRIVER'S HEATED SEAT ADJUSTER
PASSENGER'S SIDE HEATED OUTSIDE MIRROR
REAR WINDOW DEFOGGER RELAY
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/GRY WIRE
RIGHT FRONT POWER WINDOW CONTROL MODULE
ROADSTER ONLY
SECONDARY AIR INJECTION PUMP RELAY
STARTER
STARTING INTERLOCK RELAY (A/T)
TO FUSE PANEL (DIAGRAM 3 OF 4)
TO IGNITION SWITCH (DIAGRAM 2 OF 4)
W-BOX (IN ENGINE COMPT)
W-BOX (IN ENGINE COMPT) FUSE 7
W/ HEADLIGHT WASHER
WHT WIRE
WIPER/WASHER INTERMITTENT RELAY
YEL WIRE
Go to component -> Power distribution circuit (1 of 4) -> DRIVER'S SIDE HEATED OUTSIDE MIRROR
