Audi TT 8N facelift (2003-2006) combination processor gen ind Wiring diagram

This page shows the only wiring diagram for the component.combination processor gen ind, which is found in the car Audi TT 8N facelift (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram combination processor gen ind (1 of 1)

Wiring diagram combination processor gen ind for Audi TT 8N facelift (2003-2006) (1 of 1)
Get lifetime access to Audi TT 8N facelift (2003-2006)

BATTERY BLK WIRE BLU WIRE BRN WIRE COMBINATION PROCESSOR GEN IND D+ GENERATOR FUSE 11 FUSE 138 FUSE PANEL (LEFT END OF DASH) HOT IN RUN OR START INSTRUMENT CLUSTER MAIN FUSE BOX (ON TOP OF BATTERY, ON LEFT SIDE OF ENGINE COMPT) RED WIRE VIO WIRE

Go to component -> Charging circuit -> COMBINATION PROCESSOR GEN IND
