Car Wiring Diagrams for Charging circuit for Audi TT 8N (1998-2003)

B+ D+ GENERATOR BATTERY BLK WIRE BLU WIRE BRN WIRE COMBINATION PROCESSOR FUSE 11 FUSE 138 FUSE BRACKET (ON TOP OF BATTERY, ON LEFT SIDE OF ENG COMPT) FUSE PANEL (LEFT END OF DASH) GEN IND. HOT AT ALL TIMES IGNITION SWITCH INSTRUMENT CLUSTER OFF RED WIRE VIO WIRE
