Back-up lamps circuit for Audi TT 8N (1998-2003)

Back-up lamps circuit

Get access

BACK- UP LIGHT BACK-UP LIGHT SWITCH (ON TOP OF TRANSMISSION, NEAR STARTER MOTOR) BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE FUSE 7 FUSE PANEL (BEHIND LEFT END OF DASH) GRN WIRE HOT IN RUN OR START LEFT TAILIGHT ASSEMBLY NAVIGATION CONTROL MODULE RED WIRE RIGHT TAILIGHT ASSEMBLY
