Audi TT 8N (1998-2003) right headlight beam adjusting motor Wiring diagram
This page shows the only wiring diagram for the component.right headlight beam adjusting motor, which is found in the car Audi TT 8N (1998-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right headlight beam adjusting motor (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/VIO WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DATA LINK CONNECTOR
FROM VIN UP TO VIN
GRY WIRE
GRY/WHT WIRE
HEADLIGHT BEAM ADJUSTING CONTROL MODULE (BENEATH LEFT SIDE OF REAR SEAT)
HEADLIGHTS SYSTEM (HEADLAMPS CIRCUIT)
HOT IN RUN OR START FUSE PANEL FUSE 11
INSTRUMENT CLUSTER SYSTEM
LEFT HEADLIGHT BEAM ADJUSTING MOTOR
RIGHT HEADLIGHT BEAM ADJUSTING MOTOR
VIO WIRE
VIO/BLU WIRE
VIO/BRN WIRE
YEL WIRE
Go to component -> Headlamps leveling circuit, with high intensity gas discharge headlights -> RIGHT HEADLIGHT BEAM ADJUSTING MOTOR
