Audi TT 8N (1998-2003) remote rear lid unlock switch driver side interior lock switch Wiring diagram
This page shows the only wiring diagram for the component.remote rear lid unlock switch driver side interior lock switch, which is found in the car Audi TT 8N (1998-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram remote rear lid unlock switch driver side interior lock switch (1 of 1)
A/C CONTROL HEAD
ASHTRAY LIGHT
ASR/ESP BUTTON
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CIGARETTE LIGHTER LIGHT
COMBINATION PROCESSOR
CONVERTIBLE TOP SWITCH
FOG LIGHT SWITCH HEADLIGHT SWITCH LIGHT
FRONT INTERIOR LIGHT
FUNCTION SELECTOR SWITCH
FUSE 22
FUSE 23
FUSE PANEL (ON LEFT END OF DASH)
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
HEAD OFF PARK
HEATED SEAT ADJUSTERS
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL LIGHT DIMMER SWITCH
LIGHT SWITCH
MIRROR ADJUSTMENT SWITCH
NCA WIRE
PASSENGER AIR BAG OFF SWITCH
PASSENGER COMPARTMENT MONITORING SWITCH
RADIO
REAR WINDOW DEFOGGER SWITCH
REMOTE FUEL TANK DOOR SWITCH
REMOTE REAR LID UNLOCK SWITCH DRIVER SIDE INTERIOR LOCK SWITCH
WIND DEFLECTOR SWITCH
Go to component -> Instrument illumination circuit -> REMOTE REAR LID UNLOCK SWITCH DRIVER SIDE INTERIOR LOCK SWITCH
