Audi TT 8N (1998-2003) passengers heated seat temper- ature sensor Wiring diagram
This page shows the only wiring diagram for the component.passengers heated seat temper- ature sensor, which is found in the car Audi TT 8N (1998-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passengers heated seat temper- ature sensor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S BACKREST HEATING ELEMENT
DRIVER'S HEATED SEAT ADJUSTER
DRIVER'S SEAT HEATING ELEMENT
DRIVER'S SEAT SIDE BOLSTER HEATER
DRIVERS HEATED SEAT TEMPER- ATURE SENSOR
FUSE 44
FUSE 5
FUSE PANEL (ON LEFT END OF DASH)
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
NCA WIRE
PASSENGER'S BACKREST HEATING ELEMENT
PASSENGER'S HEATED SEAT ADJUSTER
PASSENGER'S SEAT HEATING ELEMENT
PASSENGER'S SEAT SIDE BOLSTER HEATER
PASSENGERS HEATED SEAT TEMPER- ATURE SENSOR
RED WIRE
SOLID STATE
WHT WIRE
YEL WIRE
Go to component -> Heated seats circuit -> PASSENGERS HEATED SEAT TEMPER- ATURE SENSOR
