Audi TT 8N (1998-2003) haldex coupling pump Wiring diagram
This page shows the only wiring diagram for the component.haldex coupling pump, which is found in the car Audi TT 8N (1998-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram haldex coupling pump (1 of 1)
AWD DRIVE CONTROL MODULE (CENTER REAR OF VEHICLE, ON HALDEX COUPLING)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BRAKE LIGHT SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
BRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
FUSE 13
FUSE 15
FUSE 31
FUSE PANEL (LEFT END OF DASH)
GRY WIRE
GRY/WHT WIRE
HALDEX COUPLING PUMP
HOT AT ALL TIMES
HOT IN ON OR START
HYD TEMP SENSOR
HYDRAULIC TEMPERATURE SENSOR
IGNITION GROUND BRAKE SW PARK BRK DIAG BATTERY CAN-L CAN-H
INSTRUMENT CLUSTER SYSTEM
NCA WIRE
OIL PRESS MOTOR
OIL PRESSURE POSITIONING MOTOR
PARKING BRAKE WARNING LIGHT SWITCH (BELOW PARK BRAKE LEVER)
PUMP
RED WIRE
RED/BRN WIRE
RED/VIO WIRE
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> 4wd circuit -> HALDEX COUPLING PUMP
