Audi TT 8N (1998-2003) foglight switch light Wiring diagrams
This page contains all the electrical diagrams for the component. foglight switch light, in which he is found in the car Audi TT 8N (1998-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram foglight switch light (1 of 3)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM
FOG LIGHT
FOG LIGHT RELAY
FOG LIGHT SWITCH OFF
FOGLIGHT IND
FOGLIGHT SWITCH LIGHT
FROM VIN
FRONT
FTP
FUSE 18
FUSE 19 FUSE 17
FUSE 20 FUSE 21
FUSE 3
FUSE 36
FUSE PANEL (ON LEFT END OF DASH)
GRN/GRY WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HEAD- LIGHTS
HEADLIGHT DIMMER/ FLASHER SWITCH
HEADLIGHT SWITCH LIGHT
HIGH BEAM IND
HOT AT ALL TIMES
HOT AT ALL TIMES IGNITION SWITCH
INSTRUMENT CLUSTER
LAMP CONTROL MODULE
LEFT FRONT HEADLIGHT/ PARK LIGHT ASSEMBLY
LIGHT SWITCH HEAD
LIGHT SWITCH/ FOGLIGHT SWITCH
MICRO CENTRAL ELECTRIC PANEL (BENEATH LEFT SIDE OF DASH)
OFF
OFF HEAD
PARK
REAR
REAR FOGLIGHT IND
RED WIRE
RIGHT FRONT HEADLIGHT/ PARK LIGHT ASSEMBLY
RUN WIRE
UP TO VIN
W/ DRIVER INFORMATION SYSTEM
W/ DRIVER INFORMATION SYSTEM W/O DRIVER INFORMATION SYSTEM
W/O DRIVER INFORM SYSTEM W/ DRIVER INFORM SYSTEM
W/O DRIVER INFORMATION SYSTEM
W/O DRIVER INFORMATION SYSTEM W/ DRIVER INFORMATION SYSTEM
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Headlamps circuit, with drl -> FOGLIGHT SWITCH LIGHT
