Audi TT 8N (1998-2003) brake light disable relay Wiring diagram
This page shows the only wiring diagram for the component.brake light disable relay, which is found in the car Audi TT 8N (1998-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake light disable relay (1 of 1)
13-FOLD RELAY PANEL (BENEATH LEFT SIDE OF DASH)
A/C CONTROL HEAD LAMP CONTROL MODULE COOLANT FAN CONTROL MODULE
A/C HIGH PRESSURE SENSOR PASSENGER'S HEATED SEAT ADJUSTER
ABS CONTROL MODULE STEERING ANGLE SENSOR ASR/ESP BUTTON
AIR BAG CONTROL MODULE LEFT FRONT POWER WINDOW CONTROL MODULE
ALL- WHEEL DRIVE CONTROL MODULE
AMPLIFIER
BLK WIRE
BLU WIRE
BRAKE LIGHT DISABLE RELAY
CENTRAL LOCKING CONTROL MODULE
DATA LINK CONNECTOR
DRIVER'S HEATED SEAT ADJUSTER
EMERGENCY FLASHER SWITCH
FROM MICRO CENTRAL ELECTRIC PANEL (DIAGRAM 1 OF 3)
FUEL PUMP RELAY
FUSE 11
FUSE 29
FUSE 37
FUSE 5
FUSE 6
FUSE 7 FUSE 31
FUSE 8
FUSE 9
FUSE PANEL (BEHIND LEFT END OF DASH)
GRN WIRE
GRY WIRE
HEADLIGHT BEAM ADJUSTING CONTROL MODULE
IGNITION SWITCH
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER, CENTRAL LOCKING CONTROL MODULE
KEY-IN IGNITION SWITCH
LOCK
MICRO CENTRAL ELECTRIC PANEL (BENEATH LEFT SIDE OF DASH)
MOTRONIC ENGINE CONTROL MODULE MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY
NAVIGATION CONTROL MODULE
NCA WIRE
OIL LEVEL THERMAL SENSOR
PARK LIGHT SWITCH
PASSENGER'S AIR BAG "OFF" WARNING LIGHT
RADIO
RED WIRE
RIGHT FRONT POWER WINDOW CONTROL MODULE
RIGHT HEADLIGHT ADJUSTING MOTOR LEFT HEADLIGHT ADJUSTING MOTOR
RUN WIRE
SPEEDOMETER VEHICLE SPEED SENSOR BACK-UP LIGHT SWITCH
STARTING INTERLOCK RELAY
TELEPHONE TRANSCEIVER
VIO WIRE
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> BRAKE LIGHT DISABLE RELAY
