Audi TT 8N (1998-2003) blk/brn Wiring diagrams
This page contains all the electrical diagrams for the component. blk/brn, in which he is found in the car Audi TT 8N (1998-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram blk/brn (1 of 5)
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLOCKING DIODE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CONVERTIBLE TOP COVER DETECTION SWITCH
CONVERTIBLE TOP COVER DETECTION SWITCH 2
CONVERTIBLE TOP FRONT LOCK SWITCH
CONVERTIBLE TOP HYDRAULIC PUMP/PUMP RELAY
CONVERTIBLE TOP LATCH OPEN POSITION SWITCH
CONVERTIBLE TOP OPEN POSITION SWITCH
CONVERTIBLE TOP OPERATION SWITCH
DEFOGGER SYSTEM
FUSE
FUSE PANEL (ON LEFT END OF DASH)
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
HOT W/ LOAD REDUCTION RELAY ENERGIZED
MICRO CENTRAL ELECTRIC PANEL (BENEATH LEFT SIDE OF DASH)
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/GRN WIRE
VIO WIRE
WIND DEFLECTOR CONTROL MODULE
WIND DEFLECTOR MOTOR
YEL WIRE
Go to component -> Convertible top circuit -> BLK/BRN WIRE
Wiring diagram blk/brn (2 of 5)
BLK/BRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BRN WIRE
BRN/BLK WIRE
DEFOGGER SYSTEM (HEATED MIRRORS CIRCUIT)
FUSE
FUSE PANEL (ON LEFT END OF DASH)
FUSE PANEL (ON LEFT END OF DASH) FUSE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEAD LIGHT SWITCH
HEADLIGHT WASHER PUMP
HOT AT ALL TIMES
HOT AT ALL TIMES OFF
HOT IN
INSTRUMENT CLUSTER
LEFT WASHER NOZZLE HEATER
LOAD REDUCTION RELAY
MICRO CENTRAL ELECTRIC PANEL (BEHIND LEFT SIDE OF DASH)
PARK
RED/GRN WIRE
RIGHT WASHER NOZZLE HEATER
RUN WIRE
VIO/GRN WIRE
WASHER SWITCH
WHT/BLK WIRE
WHT/GRN WIRE
WINDSHIELD WASHER PUMP
WINDSHIELD WIPER INTERMITTENT REGULATOR
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER/WASHER SWITCH
WIPER/WASHER INTERMITTENT RELAY
Go to component -> Front wiper/washer & headlamp washer circuit -> BLK/BRN WIRE
Wiring diagram blk/brn (3 of 5)
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/VIO WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DATA LINK CONNECTOR
FROM VIN UP TO VIN
GRY WIRE
GRY/WHT WIRE
HEADLIGHT BEAM ADJUSTING CONTROL MODULE (BENEATH LEFT SIDE OF REAR SEAT)
HEADLIGHTS SYSTEM (HEADLAMPS CIRCUIT)
HOT IN RUN OR START FUSE PANEL FUSE 11
INSTRUMENT CLUSTER SYSTEM
LEFT HEADLIGHT BEAM ADJUSTING MOTOR
RIGHT HEADLIGHT BEAM ADJUSTING MOTOR
VIO WIRE
VIO/BLU WIRE
VIO/BRN WIRE
YEL WIRE
Go to component -> Headlamps leveling circuit, with high intensity gas discharge headlights -> BLK/BRN WIRE
Wiring diagram blk/brn (5 of 5)
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
CAMSHAFT ADJUSTMENT VALVE 1 (ATC ENG ONLY)
CRUISE CONTROL SYSTEM
DISTRIBUTOR IGNITION COIL CAPACITOR
DRIVER'S DOOR CONTACT SWITCH
EMERGENCY FLASHER SWITCH, AIRBAG CONTROL MODULE, CENTRAL LOCKING CONTROL MODULE
FUEL INJECTORS
FUEL PUMP (IN FUEL TANK)
FUEL PUMP RELAY
FUSE 232
FUSE 234
FUSE 243
FUSE PANEL FUSE 228
GRN WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
MICRO CENTRAL ELECTRIC PANEL
NCA WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/VIO WIRE
TANK VENTILATION VALVE
THROTTLE VALVE CONTROL MODULE (ON THROTTLE BODY, ON LEFT FRONT OF ENG)
TO SPARK PLUGS
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
WHT/GRY WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 1.8l (3 of 3) -> BLK/BRN WIRE
