Trunk & fuel door release circuit for Audi TT 8J facelift (2010-2014)
Trunk & fuel door release circuit
BLK/RED WIRE
BLU/BRN WIRE
BRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S DOOR)
FUEL TANK LID UNLOCK MOTOR
FUSE 10
FUSE 26
FUSE PANEL C (LEFT SIDE OF DASH)
FUSE PANEL F
GRN/GRY WIRE
GRN/VIO WIRE
HOT AT ALL TIMES
ORG/BRN WIRE
ORG/GRN WIRE
REAR LID ALARM SWITCH/REAR LID CENTRAL LOCKING SYSTEM MOTOR
RED/GRN WIRE
RED/YEL WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH)
VIO/GRN WIRE
YEL/RED WIRE
