Awd circuit for Audi TT 8J facelift (2010-2014)
Awd circuit
2.5L
2.OL CDMA
2.OL CETA
ALL- WHEEL DRIVE CONTROL MODULE
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
BRAKE LIGHT, BRAKE PEDAL SWITCH (ON BRAKE MASTER CYLINDER)
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (ECM) (EXCEPT 2.5L: CENTER REAR OF ENGINE COMPT)
ENGINE CONTROLS SYSTEM
FUSE 8 FUSE 2
FUSE PANEL SC (LEFT SIDE OF DASH)
GRY WIRE
HALDEX CLUTCH CONTROL VALVE
HALDEX CLUTCH PUMP
HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED
NCA WIRE
OIL PRESSURE/ TEMPERATURE SENSOR
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
