Audi TT 8J facelift (2010-2014) 2.5l turbo, charging circuit

2.5L BATTERY BATTERY INTERRUPT IGNITER BATTERY JUMP START TERMINAL (IF EQUIPPED) BATTERY MONITORING CONTROL MODULE BLK WIRE BLU WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE FUSE PANEL D FUSE PANEL SA (LEFT SIDE OF ENGINE COMPT) GENERATOR, VOLTAGE REGULATOR INSTRUMENT CLUSTER CONTROL MODULE NCA WIRE ORG/BLU WIRE ORG/BRN WIRE RED/VIO WIRE STARTER SUPPLEMENTAL RESTRAINTS SYSTEM VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH) VIO/WHT WIRE YEL WIRE
