Power seats circuit, with backrest for Audi TT 8J facelift (2010-2014)
Power seats circuit, with backrest
BACKREST
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S BACKREST ADJUSTMENT MOTOR (SIDE OF DRIVER'S SEAT BACK)
DRIVER'S BACKREST STOP SWITCH (BASE OF DRIVER'S SEAT BACK)
DRIVER'S POWER SEAT ADJUSTMENT CIRCUIT BREAKER (IN FUSE HOLDER)
DRIVER'S POWER SEAT SWITCH
DRIVER'S SEAT HEIGHT ADJUSTMENT MOTOR (AT BASE OF DRIVER'S SEAT)
DRIVER'S SEAT INCLINATION ADJUSTMENT MOTOR (IN DRIVER'S SEAT BOTTOM)
DRIVER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
DRIVER'S SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR (IN DRIVER'S SEAT BACK)
DRIVER'S SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR (IN DRIVER'S SEAT BACK)
FORE/AFT
FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
FRONT PASSENGER'S BACKREST STOP SWITCH (BASE OF FRONT PASSENGER'S SEAT BACK)
FRONT PASSENGER'S POWER SEAT SWITCH
GRN WIRE
GRY WIRE
HEIGHT
HOT AT ALL TIMES
RED WIRE
RED/GRN WIRE
SEAT FORE/AFT ADJUSTMENT MOTOR (IN DRIVER'S SEAT BOTTOM)
SEAT FORE/AFT ADJUSTMENT MOTOR (IN FRONT PASSENGER'S SEAT BOTTOM)
TILT
VIO WIRE
YEL WIRE
