Car Wiring Diagrams for Parking assistant circuit for Audi TT 8J facelift (2010-2014)

BLK WIRE BLK/YEL WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM FUSE FUSE 7 PANEL SC (LEFT SIDE OF DASH) HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED LEFT REAR CENTER PARKING AID SENSOR (BEHIND REAR BUMPER) LEFT REAR PARKING AID SENSOR (BEHIND REAR BUMPER) ORG/BLK WIRE ORG/BRN WIRE PARKING AID CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) REAR PARKING AID WARNING BUZZER (RIGHT REAR QUARTERPANEL) RED WIRE RIGHT REAR CENTER PARKING AID SENSOR (BEHIND REAR BUMPER) RIGHT REAR PARKING AID SENSOR (BEHIND REAR BUMPER) YEL WIRE YEL/RED WIRE
