Car Wiring Diagrams for Defoggers circuit for Audi TT 8J facelift (2010-2014)

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BRN WIRE BRN/VIO WIRE CLIMATRONIC CONTROL MODULE (IN A/C CONTROL HEAD) COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE (IN DRIVER'S DOOR) DRIVER'S HEATED EXTERIOR REARVIEW MIRROR (IF EQUIPPED) DRIVER'S SIDE OUTSIDE MIRROR ASSEMBLY FRONT PASSENGER'S FRONT PASSENGER'S DOOR CONTROL MODULE (IN PASSENGER'S DOOR) FRONT PASSENGER'S HEATED EXTERIOR REARVIEW MIRROR (IF EQUIPPED) FUSE FUSE 12 FUSE 26 FUSE 27 HEATED REAR WINDOW HOT AT ALL TIMES HOT AT ALL TIMES FUSE 7 PANEL SF HOT AT ALL TIMES FUSE PANEL SC (LEFT SIDE OF DASH) ORG/BRN WIRE ORG/GRN WIRE REAR WINDOW DEFOGGER RELAY REAR WINDOW DEFOGGER SWITCH RED/GRN WIRE RED/YEL WIRE SIDE OUTSIDE MIRROR ASSEMBLY SUPPRESSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH) VIO/BLK WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WINDSHIELD ANTENNA SUPPRESSION FILTER (IN TRUNK, BEHIND LEFT SIDE PANEL)
